Power Diodes DS 2004
TECHNICAL DATA
| DEVICE TYPE | VRRM(V) | VRSM(V) |
|---|---|---|
| DS2004SD2424 | 2400 | 2500 |
| DS2004SD2626 | 2600 | 2700 |
| DS2004SD2828 | 2800 | 2900 |
| SYMBOL | CONDITIONS | VALUES |
|---|---|---|
| IDC | Tcase =85 qC | 50 amp. |
| IFSM I2t | Tvj=130qC Tvj=130qC | 500 amp. 1250 A2S |
| IRRM | Tvj=25qC Tvj=130qC | 1.0mA 7.0mA |
| VF | Tvj=25qC (IF =50 Amp.); max | 1.17 V |
| Vo Ro | Tvj=25 qC (IF = 25 Amp.); max | 0.85 V 5 mA |
| Rth(j-c) Tvj Tstg | 1.1 qC/W 125 qC 125 qC | |
| Mounting torque | 2.5 Nm | |
| Weight | Approx. | 20 gm |
| Visol | A.C. 50hz r.m.s Duration 1 min | 2500 V |
| Package Outline | IR-10,IR-11,IR-12,IR-13 |
Power Diodes DS 2004Features
- Wide current range
- High voltage ratings up to 2800 V
- High surge current capabilities
- Diffused junction
Power Diodes DS 2004Typical Applications
- Converters
- Power supplies
- Machine tool controls
- High power drives
- Medium traction applications
