Power Diodes DS 1104 DEVICE TYPE VRRM(V) VRSM(V) DS1104SG1616 1600 1700 DS1104SG2828 2800 2900 DS1104SG3030 3000 3100 CURRENT RATINGS Tcase = 75o C unless otherwise stated Symbol Parameter Conditions Max Units Double Side Cooled IF(AV) Mean forward current Half wave...

Power Diodes DS 2004

Power Diodes DS 2004 TECHNICAL DATA DEVICE TYPE VRRM(V) VRSM(V) DS2004SD2424 2400 2500 DS2004SD2626 2600 2700 DS2004SD2828 2800 2900 ​ SYMBOL CONDITIONS VALUES IDC Tcase =85 qC 50 amp. IFSM I2t Tvj=130qC Tvj=130qC 500 amp. 1250 A2S IRRM Tvj=25qC Tvj=130qC 1.0mA 7.0mA...
